Assemble the Goal
23
G
ASSEMBLE THE GOAL
8. Install cover (46) over spring return
mechanism with screws (47).
NOTE
Cover may not be included with all models.
#46
#47
9. Thread the net (26) onto the rim (25).
#26
#26
#26
#25
#25
#25
#26
#25
10. Lock elevator system into highest position
and apply 10 ft. height indication sticker
(37) to inner adjustment tube (39) directly
below arrow on handle.
11. Move elevator system to the next position
and apply the 9-1/2 ft. sticker.
12. Repeat until all height settings have been
labeled. (8-10 ft.)
#37
#39
