Introduction
Your MC9R/Encore
®
Bed is equipped with four actuators to operate following functions:
Bed up/down Adjusts the height of the bed from 7-7/8” to 31”.
Back up/down Adjusts the angle of the head deck from 0° to 70°.
Knee up/down Adjusts the angle of the knee deck from 0° to 30°.
Auto contour Adjusts the angle of the head and knee decks.
Trendelenburg Adjusts the angle of the bed from 0° to 16°.
Reverse Trendelenburg Adjusts the angle of the bed from 0° to 14°.
Comfort Chair Adjusts the angle of the bed from 0° to 14° in the Reverse
Trendelenburg position, the angle of the head deck to 57° and knee deck 30°.
CAUTION! The operating footprint of the bed can range from 96” L x 36”W to 115” L x 76”W
depending on bed size configuration, options, bed positioning and option positioning. Before operating
the bed, please check all areas around bed to ensure there are no fixed or movable objects within the
bed’s operating footprint throughout the height range of the bed. Failure to do so could result in
property damage or injury.
This instruction manual covers options and accessories which may not be included on your bed.
Before operating your MC9R/Encore
®
, be sure that you have completely read and understood the
instructions and warnings contained in this manual and included with the accessories.
Unpacking Instructions - (PLEASE RECYCLE)
Your MC9R/Encore
®
bed is shipped in a vertical position with the Head-End on the ground. If it has not been
lowered flat, then two people are required to lower it gently to the ground.
Cut the "shipping ties" securing the deck to the frame. There are also ties securing wiring in place, care must
be taken so that only the red "shipping ties" are removed.
Remove the packaging attached to the frame containing the Mattress Stops and the Board Mounting Brackets.
Make sure that all parts are included prior to disposing of the packaging material and immediately report any
missing parts to Span Medical Products Canada Customer Service.
