Attaching your machine to the tractor – using 3
point linkage
Avoid raising the tractor linkage once the stabiliser bars are locked
in place.
Always lower the tractor linkage and allow all the weight to be
carried by the stabiliser frame. Failure to observe this warning will
result in bending the stabiliser frame.
22. Warning - fully tighten chains and linkage
stabilisers to hold the machine rigid. There must
be no sideways movement, it is very dangerous.
23. Remove parking stands and store safely.
The machine can not be unhitched without these
stands.
24. Use only tractors with safety glass. If
windows are not laminated safety glass,
polycarbonate glazing must be fitted between
operator and cab meshing. Shape mesh to
cover all windows that the driver will look
through to view flail head in any operating
position. Mesh can be retained by springs and
clips supplied, but it is the operators
responsibility to ensure guarding is firmly in
Excel 606, 686, 726 & 836
