Moving into transport position
Always transport machine with the slew-locking pin and transport link
Fitted and their arms closed in their transport position on the bump
stops.
Avoid high transport
speeds, which will cause unnecessary strain on machine
and tractor.
Never travel with the reach arm away from bump stop on the main arm failure to adhere to this
warning will cause damage to ram seals and arms.
Do not attempt to move the main lift ram until transport link has been removed. Failure to
adhere to this warning may cause damage to the frame, link or ram.
1. Disengage head motor drive.
Ensure that the lift and angle float are discharged and
turned off.
Retract arms to bring flail head approx. 1metre from
tractor wheel and 1 metre off the ground (close
telescopic or VFR where applicable).
Slew rearwards to fully close slew ram
2. Gently close reach arm into cradle and bump stop
on main arm.
Excel 606, 686, 726 & 836
