Attaching your machine to the tractor – using 3
point linkage
11. Fit stabiliser yoke to the tractor’s top hitch
bracket.
12. Place the stabiliser tubes on to the frame
using the pins. Swing forward stabiliser bars
and attach to stabiliser yoke. Be sure the
stabiliser bars are free to slide. Do not fit
locking pins.
13. Fit top link to machine and the tractor
14. Caution: when positioning the top link, it is
most important to select the most suitable hole
position to achieve as near as possible a
straight line between all 3 holes.
Excel 606, 686, 726 & 836
