Spearhead Excel 606 - Page 3

Operation
. Angle Float…………………………………………….……..….….……33
Head Float……………………..………………………………………….34
Debris Blower……………..……………………………………………...35
Hydraulic Rear Roller..…………………………………………………..36
Autopilot………….………………………………………………………..37
Quad saw…………….……………………………………………………42
Telescopic Arm………………………………………...…………………45
Variable Forward Reach…………………………………………………46
Service & Maintenance
Greasing / Lubrication…………………………………….………….…47
Hydraulic hoses………………………………………..…..……….…...49
Oil Supply………………………………………………..…..……….….50
Oil Recommendations…………………………………..…..……….…50
Filtration Maintenance………………………………….….………......50
Flail Head…………………………………………………….…………..51
Pin & Bushes, Storage…………………………………………..….…52
Torque Settings…………………………………………………..….…53
Regular Service Chart……………………………………………..….53
Diagnostics
Troubled shooting Excel / Highway………………………..………..54
Pump and Motor failure……………………………………………….57
Hydraulic Diagram…….………………………………………….……60
Notes……………………………………………………………….……62
Warranty
The Spearhead Warranty……………………………………………..63
Extended Warranty……………………………………….……………64
Excel 606, 686, 726 & 836
3
