Lubrication Chart
Greasing / Lubrication
Washing your machine
Grease all your machine and optional parts after each time you wash your machine.
Gearbox
Gearbox oil level / quantity 380cc. Replace after 50hrs then once a year
with EP90 Note: Do not over tighten filler / drain plugs, as this will
damage gearbox casing.
P.T.O.
Dismantle, clean the input drive shaft sliding surfaces and re-grease, failure to do this
will result in serious damage to the gearbox. Grease both U.J. joints every 8 hours.
Motor Drive - Direct Drive
Motor drive splines are lubricated via the rotor bearings and should be greased every
8 hours with 10-30 pumps of grease.
Motor Drive - Belt Drive
Motor drive splines are lubricated via the pulley shaft and should be greased every 8
hours with 5-10 pumps of grease
.
Oil requirements
Fill the tank to centre of sight gauge with
approximately 200 litres of Texaco Rando
HD46 or equivalent oil. Do not over fill.
Excel 606, 686, 726 & 836
