4
 Do not use a high pressure water spray directly on the bearings. Even water from a garden
hose can penetrate bearing seals and crank interfaces, which can result in increased
bearing and crank wear, which can affect the normal function of the bearings. Use a clean,
damp cloth and bicycle cleaning agents for cleaning.
 Do not expose the bicycle to prolonged direct sunlight or excessive heat, such as inside a car
parked in the sun or near a heat source such as a radiator.
WARNING! Failure to follow the instructions in this section may result in damage
to the components on your bicycle and will void your warranty, but, most
importantly, may result in serious personal injury or death. If your bicycle exhibits
any signs of damage, do not use it and immediately bring it to your Authorized
Specialized Retailer for inspection.
A
B
M
C
D
P
E
F
G
H
I
J
K
L
N
O
4. SPECIFICATIONS
4.1. GEOMETRY
FRAME SIZE 49 51 54 56 58 61
A STACK (MM)
514 527 544 565 591 612
B REACH (MM)
375 380 384 395 402 408
C HEAD TUBE LENGTH (MM)
109 120 137 157 184 204
D HEAD TUBE ANGLE (°)
71.75 72.5 73 73.5 73.5 74
E BB HEIGHT (MM)
266 268
F BB DROP (MM)
74 72
G TRAIL (MM)
63 58 55 52
H FORK LENGTH, FULL (MM)
369
I FORK RAKE/OFFSET (MM)
47 44
J FRONT CENTER (MM)
574 577 579 591 606 613
K CHAINSTAY LENGTH (MM)
410
L WHEELBASE (MM)
973 975 978 991 1005 1012
M TOP TUBE LENGTH, HORIZONTAL (MM)
508 531 540 562 577 595
N BIKE STANDOVER HEIGHT (MM)
776 800 818 839 866 894
O SEAT TUBE LENGTH (MM)
431 462 481 504 532 567
P SEAT TUBE ANGLE (°)
75.5 74 73.5 73
