4.2. SMALL PARTS SPECIFICATIONS (COMMON PARTS)
The S-Works models are compatible with electronic shifting only (wired or wireless). All other
models are compatible with electronic or mechanical shifting systems.
PART # DESCRIPTION TOOL SIZE in-lbf Nm
A
FRAME
B
FORK
C
S201900005 *FRONT DERAILLEUR (FD) HANGER 2.5mm 18 2.0
D
S201900002 RUBBER FD BLOCK OFF PLATE
E
S206000001 REAR DERAILLEUR (RD) HANGER 4mm 40 4.5
F
S174700006 SEAT COLLAR 4mm 55 6.2
G
S204900004
SEATPOST (FRONT RAIL CLAMP BOLT) 4mm 26.5 3.0
SEATPOST (REAR RAIL CLAMP BOLT) 5mm 55 6.2
H
S186800006 Di2 BATTERY SLEEVE
I
S200200010 FRONT AXLE 6mm 133 15.0
J
S200200011 REAR AXLE 6mm 133 15.0
K
WATER BOTTLE 3mm 25 2.8
L
S179900013 CABLE HOUSING FERRULE
M
S202500013 STEM TOP CAP 4mm
N
S202500012
HEADSET COVER
O
COMPRESSION RING
P
UPPER HEADSET BEARING
Q
LOWER HEADSET BEARING
R
S202500011 EXPANDER PLUG 6mm 55 5.1
S
S209900054 REAR DERAILLEUR PLUG (WIRED)
T
S179900015 REAR DERAILLEUR PLUG (WIRELESS)
U
S200700001 FRONT BRAKE CALIPER PLATE
4.3. SMALL PARTS SPECIFICATIONS (MECHANICAL COMPATIBLE FRAMES)
PART # DESCRIPTION TOOL SIZE in-lbf Nm
V
S186500003 DOWN TUBE ICR COVER PLATE 2.5mm 7 0.8
W
S186500004 DOWN TUBE ICR MECHANICAL PORT 2.5mm 7 0.8
X
S206500011 BOTTOM BRACKET CABLE GUIDE
Y
S172000002 CHAINSTAY CABLE GUIDE 3mm 25 2.8
4.4. SMALL PARTS SPECIFICATIONS (S-WORKS MODELS)
PART # DESCRIPTION TOOL SIZE in-lbf Nm
C
S201900005
*FRONT DERAILLEUR (FD) HANGER 2.5mm 18 2.0
Ca
FRONT DERAILLEUR HANGER
BACKING PLATE
The Aethos frame is available in two frame configurations, 12R (S-Works
models) and 10R (all other models).
The 12R frames are compatible with electronic shifting systems only. A custom
backing plate is required to mount the front derailleur hanger. Information
specific to 12R frames is covered in section 5.1 (highlighted in BLUE).
The 10R frames are compatible with electronic or mechanical shifting
systems. Information specific to mechanical shifting system installation is
covered in section 5.3 (highlighted in ORANGE).
Many bolts have a blue threadlock patch on the threads to help secure the
bolt under torque. Repeated installation and removal of a bolt may reduce the
effectiveness of the patch. However, it can be replaced with the application of
a liquid blue threadlocker.
*Part C (Front derailleur hanger): The same hanger is used on all models.
However, the S-Works model also requires a backing plate. For additional
information, refer to section 5.1.
