11. SPECIFICATIONS
11.1. GENERAL SPECIFICATIONS
DESCRIPTION SPECIFICATION
HEADSET BEARING
1 1/8” UPPER / 1.5” LOWER
SEAT COLLAR DIAMETER
42.9 mm
SEATPOST DIAMETER
34.9 mm
DERAILLEUR HANGER*
AMAZINGER 2.1, MTB RD HANGER
BELT
GATES CARBON DRIVE 11M-122T-12CT BELT CDX 122T BLACK
* Non-enviolo equipped models only
11.2. TOOLS REQUIRED
2.5, 3, 4, 5, 6, 8 mm ALLEN (Hex) KEYS GREASE
TORX T10, T20, T25, T30 DRIVER CASSETTE LOCK RING TOOL
13 mm SOCKET WRENCH THREAD LOCKER COMPOUND
15 mm OPEN WRENCH
11.3. BOLT SIZE / TOOLS / TORQUE SPECIFICATIONS
WARNING! Correct tightening force on fasteners (nuts, bolts, screws) on
your bicycle is important for your safety. If too little force is applied, the
fastener may not hold securely. If too much force is applied, the fastener can
strip threads, stretch, deform or break.
Either way, an incorrect tightening force can result in component failure,
which can cause you to lose control and fall. Where indicated, ensure that
each bolt is torqued to specification. After your first ride, and consistently
thereafter, recheck the tightness of each bolt to ensure secure attachment of
the components.
The following is a summary of torque specifications in this manual:
LOCATION TOOL
TORQUE
NM IN-LBF
SEAT COLLAR
4 mm Hex 6.2 55
SEATPOST RAIL CLAMP BOLTS
5 mm Hex N/A N/A
STEERER TUBE CLAMP
TX25 6.2 55
STEM TOP CAP BOLT
5 mm Hex N/A N/A
CRANK BOLTS
8 mm Hex 50 443
CHAINRING BOLTS
5 mm Hex 10 89
WATER BOTTLE CAGE BOLT
3 mm Hex 2.8 25
12 mm REAR AXLE **
6 mm Hex 15 133
ENVIOLO AXLE NUTS **
15 mm WRENCH 30 - 40 265 - 354
DERAILLEUR HANGER *
4 mm Hex 6.2 55
HEAD TUBE ICR GUIDE SCREW
TX10 0.8 7
MOTOR MOUNT NUTS
13 mm SOCKET
WRENCH
23 203
MOTOR MOUNTING BOLT
5 mm Hex 23 203
MOTOR COVER CUSTOM NUT
TX20 1 8.8
REAR DROP OUT COVER BOLT
2.5 mm Hex 1 8.8
ADJUSTABLE DROPOUT MOUNTING
BOLTS*
TX30 13 115
ADJUSTABLE DROPOUT ADJUSTMENT
BOLTS*
3 mm Hex N/A N/A
