Specialized Enduro Comp - 7. Forward Shock Eye Assembly; 8. Flip Chip Geometry Adjustment

16
7. FORWARD SHOCK EYE
Y: FORWARD SHOCK EYE SPACERS
10.1 ID x 15 OD x 7.5 W
 Grease, then install the forward shock eye spacers (x2) Y into the bearings.
8. FLIP CHIP - LOW SETTING
LL: FLIP CHIP SPACERS
8 ID x 15 OD x 6.5 W
HOLE POSITIONED
TOWARD THE FRONT
FLIP CHIP - HIGH SETTING
LL: FLIP CHIP SPACERS
8 ID x 15 OD x 6.5 W
HOLE POSITIONED
TOWARD THE REAR
 Grease, then install the Flip Chip spacers (x2) LL into the rear shock eye. Choose the high
or low chip position.
