Spectra Precision DG613 Information Guide

1
2
3
4
5
1. Extension Bar – allows for one-inch (25 mm) coarse adjustments in the T-Bar’s overall length.
2. Locking Pin – holds the extension bar in place.
3. Mounting Plate – supports the Laser or the 1239 Universal Fixed Pole.
4. Speed Release Handle – tightens the T-Bar into place and allows for quick release.
5. Horizontal Lock Knob – allows the mounting plate to slide freely along the extension bar and
positions the laser on line.
Reading
edge
Fixed pole
Locking pin
Horizontal
lock
Adjustable
pole lock

Spectra Precision DG613 Specifications

General

Brand	Spectra Precision
Model	DG613
Category	Measuring Instruments
Language	English
