Spectra Precision DG813 User Manual

7. Axis Alignment Markers - used to align
the laser when the line system is centered.
8. Mounts for scope adapter – to
attach the optional scope adapter for the
„Over the Top“ application
9. 5/8”-11 Threaded Mount – to attach the
laser to various setup accessories
10. Remote Receiver Window – receives
signals from the RC803 and SF803
11. Beam-Exit Window – provides a
clear window for the laser beam to exit
the pipe laser.
DG813/DG613 Components
10
11
7
9
8
