3 General Operation
26 EPOCH 50 GNSS System User Guide
Self-test procedure
Note – You cannot turn the power off during the self-test.
The following messages are displayed during the self-test procedure that occurs each
time the receiver is turned on:
The GNSS status is displayed when the self-test is finished. Initially the display shows
0/00 while the receiver is acquiring satellites. It can take several minutes to update,
especially if the receiver has been turned off for a long time, or if the physical location
of the receiver has changed significantly while the receiver was off. Once the GNSS
status is updated, the first character indicates the quality of position as described
below, followed by the number of satellites being tracked:
• 0 No GNSS solution
• A Autonomous
• D RTK float solution (differential)
• F RTK fix solution
Far Right position
When the receiver is operating and a post-process data collection is running, the letter
R appears in the far right position of the display to indicate that data is being recorded.
Message Description
EPOCH Welcome message
Self-test procedure
V#.# MPU firmware version
Ready Self-test passed
