CHARGING & BATTERIES
6
The Spectra range is divided into two groups. Alkaline only Laser Levels which run on 2 x
Type “D” Alkaline Batteries and Rechargeable Laser Levels which either run on a 5,000mAH or
10,000mAH Rechargeable battery pack. Only the Spectra LL300N, LL300S, HV302, HV302G &
GL422N rechargeable lasers are supplied with the Spectra SMC62 Worldwide Charger 6.2V.
Spectra SMC62 Worldwide Charger 6.2V
This is the Genuine Spectra Precision® Plug-in Mains Charger 6.2V for WORLDWIDE use. All plug
adapters (UK, US/CAN, EU & AUS/NZ) are included. (This Charger is NOT recommended for use
with any other equipment).
The 6.2 Volt 700mA charger (Input 100-240V AC 50-60Hz Output DC 6.2V, 700mA, centre pin +
polarity Double insulated CE mark) is for indoor use only. If the charger becomes damaged, stop
using immediately and purchase a replacement. Never use a generic charger with this laser.
● The general procedure to adopt is to use the laser during the day & charge-up overnight. You
cannot damage the system by “over-charging” the batteries.
● When the Charger is plugged into a mains electric socket, it’s LED illuminates GREEN.
● Plug the charger into the charging port located on the side wall of the laser.
● It remains green when plugged into the laser. It never fl ashes nor changes colour when
operating correctly.
● The laser’s battery LED indicator only slowly fl ashes RED when the battery is low power and
requires charging.
● The Mains Charger will charge most batteries in around 6-8 hours. It takes 4 to 5 charge/
discharge cycles for these battery packs to reach their maximum capacity.
IMPORTANT
When the plug is connected into the laser’s charging socket, there is
NO indication on the keypad of the laser or on the charger to confi rm
charging is in progress. This is applicable to all Spectra Rotary lasers
and is NORMAL.
