©2023 Spectra Precision | All Rights Reserv ed
Grade Enter Digit select mode
M (Menu) button
Press M (Menu) button to open the menu. >>Grade<< will be shown.
Press E (Enter) button. Both grade values will be shown and the cursor flashes at the +Y
sign.
Press left/right arrow button to move the cursor to the left and right and in a circle to the
next row.
Press up/down arrwow button to change the sign (grade reverse) and set the desired digit.
For quick toggling the cursor between the X and Y axis, press the Manual button.
Press and hold the Manual button for two seconds sets the grade value of the current acis
to 0%.
Press Enter button to confirm the selected grade value and to return to the standard
display.
Press the M button to return to standard display at any time and to escape from submenu.
Note: The A symbols at the LCD will flash until the laser has self-leveled to the requested
grade position.
Up/down arrow buttons
E (Enter) button
Manual button
Left/right arrow buttons
