Spectracom Pendulum PathAlign-R 2200 - Mechanical; Environmental; Supplemental Specifications; Battery Charger

PathAlign-R Spectracom Corporation
2200 / 2240 / 2241 PathAlign-R Manual
1-8
1.5.7 Mechanical
Power:
DC, 12 VDC, 2.3 Ah, Rechargeable Sealed Lead Acid Battery.
Weight:
Net: 3.2 kg (7 lbs.) per unit (inc battery and backpack)
Shipping: 5 kg (11 lbs.)
Dimensions (HxWxD):
89mm x 213mm x 333mm (3.5 in. x 8.375 in. x 13.1 in.)
Connectors:
RF In / Out:
Super SMA female sparkplug, field replaceable.
Headset In / Out:
3.5 mm (1/8") front panel jack (earpiece = ring conn. ; mic = tip
conn.)
Remote Readout:
BNC rear panel connector (0-2 VDC Out; 1mV = 0.1 dB)
Battery Charger In:
5.5 mm x 2.1 mm rear panel Power jasck (15 VDC/ 1A, center
positive)
1.5.8 Environmental
Designed to meet EN 61010-1 (IEC 1010-1)
Operating Temperature:
-10°C to 40°C (14°F to 104°F)
Storage Temperature:
-40°C to 71°C (-40°F to 160°F)
Relative Humidity:
95% ±5% 10°C to 30°C; 75% ±5% to 40°C; 45% ±5% above
40°C
Burn In:
Failure-free burn in of no less than 100 hours at 40°C
Pollution Degree:
1 (no pollution) (EN 61010-1/3.7)
Transient Overvoltage:
Installation Category II (EN 61010-1/J)
1.5.9 Supplemental Specifications
Warranty:
One Year Limited Warranty
Montreal Protocol:
Nil Return
ISO 9001:
All Spectracom sites are registered to ISO 9001:2008 and are
regularly audited and improved to provide you the best
possible vendor support.
CE (European Union):
EN 55011: 1998 w/A1:1999; Group 1 Class B (emissions)
EN 61326-1:1997 w/A1:1998 (immunity)
1.5.10 Battery Charger
ACS MAINS Input:
90 to 264 VAC / 47 to 63 Hz
AC MAINS Connector:
IEC-320, 3-conductor. Conforms to IEC 320-3:1987/EN 60 320
