range).
15 GHz
18.1-19.4 GHz
22-23.5 GHz
(Band 4)
Red LED. Illuminates when Band 4 is active (thumbwheel
switch has selected a frequency that is within the Band’s
range).
Battery Charge Indicator
Icon in LCD Display. The front panel LCD meter has a low
battery annunciator in its upper left hand corner. This battery
annunciator will be displayed when the battery has
approximately 15 minutes of its charge left. Additionally, when
the bat
tery charge becomes insufficient to properly operate the
unit.
3.2.4 Connectors
This section identifies the front panel connectors.
Name
Function
HEADSET
3.5 mm (1/8”) 3 conductor jack provides the Headset
connection for both the microphone and the earpiece. The
’Sleeve’ connector is common (Gnd.); the ’Ring’ connector
outputs the received modulation for 8-
ohm earpieces, and the
’Tip’ connector received the voice modulation from the
headset’s electret microphone. 5 VDC, in series with a 2.2k
resistor, on the ’
Tip’ connector provides the electret
microphone’s bias voltage.
1.5-2.5 GHz
(Band 1)
Super SMA female sparkplug type connector provides antenna
Transmit/Receive frequencies from 1.5 GHz to 2.5 GHz/ 50Ω.
3.5-5.0 & 5.8-6.6 GHz
(Band 2)
Super SMA female sparkplug type connector provides antenna
Transmit/Receive frequencies from 3.5 GHz to 5.0 GHz and
5.8 GHz to 6.6 GHz/ 50Ω.
7.5-10 & 11-12 GHz
(Band 3)
Super SMA female sparkplug type connector provides antenna
Transmit/Receive frequencies from 7.5 GHz to 10.0 GHz and
11.0 GHz to 12.0 GHz/ 50Ω.
15 GHz
18.1-19.4 GHz
22-23.5 GHz
(Band 4)
Super SMA female sparkplug type connector provides antenna
Transmit/Receive frequencies from 18.1 G
Hz to 19.4 GHz and
22.0 GHz to 23.5 GHz and 15 GHz/ 50Ω.
Caution: When connecting the SMA terminated end of the cable to the front panel Band
connector, do not over-tighten the SMA cable connector as it can damage the front
panel connector’s center pin. A 5/16” open end wrench fits SMA connectors;
recommended torque is 8-inch/pounds. A special 5/16” open end is available from
Torque Controls, So. El Monte, California. The manufacturer part number is ’A5’.
Caution: Damage may be sustained by the PathAlign-R if greater than +10 dBm is
applied to the SMA connectors.
