DC Output:
15 VDC / 1A
DC Connector:
5.5 mm x 2.1 mm Barrel Power connector, 5 foot cord
Dimensions (HxWxD):
33 mm x 51 mm x 86 mm (1.3 in x 2.0 in x 3.4 in)
Operating Temperature:
0°C to 40°C (32°F to 104°F)
1.5.11 Record-R Specifications (Model 2241 / 2241A Only)
Data Recorded:
Each record contains: Model No, Serial No., Date, Time (UTC),
Longitude, Latitude, Frequency, & Path Loss
Data Record Time:
~20 milliseconds
Data Format:
CSV (comma-separated variable)
Max No. of Records
250 (stored in instruments non-volatile memory)
Downloading Records:
Records are downloaded, thru RS-232-
C or USB rear panel
connectors.
Downloading Baud Rate:
9600 Baud.
Software (included):
LogView-R Data Log Utility software for Windows operating
systems. This software allows a remote computer to download,
display, and s
ave data records and clear the instrument's
memory.
GPS:
Frequency:
L1 (1575.42 MHz), C/A code (SPS), 8-channel cont. tracking,
32 correlators.
Position Accuracy:
±2 meters CEP (50%)
Timing Accuracy:
±95 nano-seconds
Position Fix Update:
1 second
Time To Lock:
Cold Start: < 130 seconds (90%); Warm Start: <45 seconds
(90%); Hot Start: <20 seconds (90%)
Reacquisition Time:
<2 seconds (90%) after loss of signal.
Mechanical:
RS-232-C Connector:
DB-9 female (rear panel)
USB Connector:
USB type B female (rear panel)
1.5.12 Accessories Furnished
With each of the set's two (2) units:
One (1) Operating/Maintenance Manual with User Information Card
One (1) Headset with noise cancelling mic.
