1. Please note that the Smartphone adapter
included only works with the 10mm and
20mm eyepiece that come with the
telescope.
2. Open the phone clamp and clamp the phone
securely. (See Fig. 18)
3. Loosen the big knob and rotate the phone
clamp around until the camera is aligned with
the hole on the phone clamp. (See Fig. 19)
4. Remove the eye relief from the eyepiece to
reveal the teeth. (See Fig. 20)
5. Align the adapter and the eyepiece, then
rotate the eyepiece to lock the two together.
(See Fig. 21)
6. Insert the eyepiece and adapter back into the
diagonal. Loosen the knob on the back of the
phone adapter to move the phone around.
7. Turn on the camera APP and rotate the
phone until a perfect circular view appears on
the screen. Then re-tighten the knob to lock
the phone’s position.
8. Focus the telescope and take a picture
through the telescope.
SETTING UP
Using with a Smartphone
FIG.18
FIG.19
FIG.20
FIG.21
11
ASTROLITE TELESCOPE
