GRILLE / SURFACE MOUNT
Single Color Wiring Diagram
Wire Color Function
Red*
Positive
Black*
Negative
Yellow
Flash Pattern
Dual Color Wiring Diagram
Wire Color Function
Red*
Positive
Black*
Negative
Yellow
Flash Pattern
* Indicates a main power cable.
Single Color Specications
Voltage 12 VDC
Amps < 0.25
Optic TIR / Linear
LED Count TIR: 3 / Linear: 3
Cable Length 1’
Flash Patterns 13
Dual Color Specications
Voltage 12 VDC
Amps < 0.25
Optic TIR / Linear
LED Count TIR: 6 / Linear: 6
Cable Length 1’
Flash Patterns 13
Wire Color Function
Green
Steady Burn Override
White
Sync (Max 8 Units)
Blue
Alternating Sync Flash Pattern Programming
Wire Color Function
Green
Steady Burn Override
White
Sync (Max 8 Units)
Blue
Dual Color Mode / Alternating Sync Flash
Pattern Programming
NOTE: All cables except Negative contact +12 VDC.
NOTE: Single Color and Dual Color Z-3 units have slightly di󰀨erent features. They are noted where applicable.
