SpeedyBee BEE25 - Page 7

BindingBinding Successful
Binding Button
Indicator Light
It is recommended to check if the firmware of the module and the receiver are
consistent before binding. If not, please use the SpeedyBee app for firmware updates.
TBS NanoRX
XFnano
45
XFnano
45
XFnano
45
1.Press and hold the Bind button on the TBS receiver while powering it on until the
green light flashes rapidly, then release the Bind button. Press and hold the Bind
button again for 8 seconds, then release it. Wait for the green light on the receiver
to turn off and the red light to flash slowly. The remote controller screen will show
"Update micro RX?", then select "ENTER".
2.Wait for the update to complete and automatic binding. Once binding is successful,
the remote controller will display "Binding OK", and the green light on the TBS receiver
will be solid.
TBS Receiver Binding
1.Power the drone on and off three times to put the receiver into binding mode.
The LED on the receiver will flash twice quickly, indicating the receiver is in
binding mode.
2.For the RadioMaster TX16S remote controller, press and hold the SYS button to
enter the TOOLS interface, scroll down to select ExpressLRS, then select Bind and
press Enter.
3.When the receiver has a solid LED on, it indicates that the receiver binding
is successful.
ELRS Binding
TOOLS
01 FrSky GaSsuite
02 FrSky SBEC
03 FrSky SxR
04
crossfire
05 ......
CROSSFIRE SETUP
XF Micro TX
XF Wifi
SET Fallsafe
Bind
Ceneral
Max Power
Dyn Power
Frequency
......
Open
25mW
Off
915MHz
XF Micro TX
SET Fallsafe
Bind
Ceneral
Max Power
Dyn Power
Frequency
......
Open
25mW
Off
915MHz
XF Micro TX
Binding
[EXIT]
SET Fallsafe
Bind
Ceneral
Max Power
Dyn Power
Frequency
......
Open
25mW
Off
915MHz
XF Micro TX
Update Micro RX?
[EXIT][ENTER]
SET Fallsafe
Bind
Ceneral
Region
Dyn Power
Frequency
Max Power
Open
25mW
Off
915MHz
XF Micro TX
[Binding OK]
