11SPEKTRUM DX8e • TRANSMITTER INSTRUCTION MANUAL
EN
BINDING
Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifi er) code of a single specifi c transmitter.
You must bind the receiver to your transmitter before it will operate.
Binding Using the Receiver and Receiver Battery
Binding Using the Receiver and ESC
1. Lower throttle to the lowest position and make sure the
transmitter is powered off.
2. Insert the bind plug into the BIND/DATA port.
3. Insert the receiver battery into ANY open port. The receiver’s
LED will fl ash when the receiver is ready to bind.
4. While pressing the Bind button, power on the transmitter.
5. Release the Bind button after the receiver has stopped
fl ashing rapidly, once the receiver’s LED stays illuminated; this
indicates the receiver is bound to the transmitter. The screen
also provides binding information.
6. Remove the bind plug from the receiver.
1. Lower the throttle to the lowest position and make sure the
transmitter is powered off.
2. Insert the bind plug into the BIND/DATA port.
3. Insert the ESC plug into the THRO port.
4. Connect the battery to ESC and turn on the ESC switch,
if available. The receiver’s LED will fl ash rapidly when the
receiver is ready to bind.
5. While pressing the Bind button, power on the transmitter.
6. Release the Bind button after the receiver’s LED stays
illuminated. This indicates the receiver is bound to the
transmitter. The transmitter screen also provides binding
information.
7. Remove the bind plug from the receiver.
2
5
3
6
1
5
2
6
3 4
7
1
4
