24 SPEKTRUM NX6 • TRANSMITTER INSTRUCTION MANUAL
EN
The System Settings menu consists of four screens:
System Settings, Extra Settings, Serial Number and Calibrate.
Select NEXT or PREV to move between screens.
The User Name eld displays your name in the lower right corner
of the main screen.
To Program a User Name:
1. Scroll to User Name and press the scroll wheel. The User
Name screen appears.
2. Scroll to the desired character position and press the scroll
wheel. Scroll left or right to change the character and press
the scroll wheel to save the selection. The User Name can
contain a maximum of 20 characters, including spaces.
3. Press the Back button to save the User Name and return to
the System Settings screen.
The Backlight eld adjusts the backlight appearance time and bright-
ness. You have the option to turn the backlight off for models you y
during the day and turn the backlight on for night ying models.
The backlight time options are:
Off: Appears for a short time when you power on the transmitter.
On: The backlight is always on.
Set Time: The backlight is on for 3, 10, 20, 30, 45 or 60
seconds before automatically turning off. Press the scroll
wheel once to turn the backlight on.
The backlight percentage adjusts the backlight intensity and it
is adjustable in 10% increments from 10% (darker) to 100%
(brighter).
SYSTEM SETUP
SYSTEM SETTINGS
Palette Utilities
User Name
Backlight
You can easily change the transmitter Modes from 1, 2, 3 and
4. Use the slider found on the back of the transmitter to change
between modes (2, 4) and (1, 3).*
Finish the mode change by following the programming steps
below.
To change the gimbal stick mode:
1. Scroll to Mode and press the scroll wheel.
2. Scroll left or right to change the gimbal stick mode. Press the
scroll wheel to save the selection.
3. Select NEXT in the lower left corner until the Calibration
screen appears.
4. Move all transmitter controls to the center position and
complete the calibration process before exiting the System
Settings menu. See “Calibrating Your Transmitter” for more
information.
*For more information, see Physical Transmitter Adjustments
in the back of the manual.
The Battery Alarm is set to LiIon battery type for the NX6 and
cannot be changed. The alarm activates when the battery reaches
the low voltage limit.
To change the battery voltage trigger point for the alarm:
1. Scroll to the battery voltage and press the scroll wheel. Turn
the scroll wheel left or right to change the voltage level. Press
the scroll wheel again to save the selection.
Battery Alarm
Mode
The colors on the NX6 may be customized as you wish. Select
from the pre-dened color options listed under Global Customized,
or select Personalize to create your own RGB color scheme.
To Next Page
