3.3.5. Scintillator Output and Cables
This uses a bespoke ’Poke home’ receptacle manufactured by Spellman HV with an 9mm ISO metric
thread, 39mm deep. See drawing in Appendix 3 – Scintillator Cable Assembly.
Different lenghts scintillator mating cables for the ‘Poke home’ receptacle are available to order.
Scintillator Cable Assembly part number
Cable Length
HVC11/1SO/1320
1m
HVC11/1SO/1316
2m
3.3.6. PMT and Collector Outputs
These outputs use an industry standard BNC.HT connector (i.e. Radiall R316 553)
