Figure 1 – J3, RS-232 DB-9M pin out (front view)
PIN
DESCRIPTION
1
-
2
Tx Out
3
Rx In
4
-
5
Ground
6
-
7
-
8
-
9
-
3.2 RS-232 CABLING
A standard shielded RS-232 cable should be used to connect the XRB
serial port to the serial port on a standard personal computer. Please refer
to the following chart.
3.3 ETHERNET INTERFACE
The Ethernet interface has the following attributes:
• IP Port - 50001
• IP Address 192.168.1.4, set as default. See Appendix B for
instructions to change the IP address.
PC to XRB Board Cable Details
PC Connector (DB-9 Female)
XRB Connector (DB-9 Male)
Pin 2: RX In
Pin 2: TX Out
Pin 3: TX Out
Pin 3: RX In
Pin 5: Ground
Pin 5: Ground
