1.1 Ratings
The units provide the following rated HV outputs:
Unit
Voltage
Current
MPD2.5P10/24
+2.5kV
4mA
MPD2.5N10/24
-2.5kV
4mA
MPD5P10/24
+5kV
2mA
MPD5N10/24
-5kV
2mA
MPD10P10/24
+10kV
1mA
MPD10N10/24
-10kV
1mA
MPD15P10/24
+15kV
0.67mA
MPD15N10/24
-15kV
0.67mA
MPD20P10/24
+20kV
0.50mA
MPD20N10/24
-20kV
0.50mA
MPD30P10/24
+30kV
0.33mA
MPD30N10/24
-30kV
0.33mA
The input rating for all units is 24Vdc ±2V, 1A
Unit masses:
2.5kV to 10kV units 420g
15kV and 20kV units 650g
30kV units 950g
Environmental conditions:
The operating temperature range is 0°C to +50°C.
Relative humidity rating (RH)% is 20% to 85% (non-condensing).
Altitude 0 to 2000m above mean sea level
