Appendix 1. Mechanical Outline 2.5kV to 10kV units.
130.0
70.0
Fixing face
15w D-plug
Customer Adjust Point
70383
46.014.0
49.0
28.0
MOUNTING HOLE TEMPLATE
(NOTE - Max thread depth into unit is 5mm)
TOP OF UNIT
7.0
Unit Footprint
30.0
SIDE OF UNIT
CALIBRATION
VOID IF SEAL
BROKEN
HOLE Ø3.5mm
IN 3 POSITIONS
