4. Operation of the Units
The units are operated by either analogue input, using any of the methods detailed below, or
by digital control using an RS232/485 serial port with a PC connection and a suitable
interface.
4.1 Analogue Control
4.1.1 Control and Monitoring Signals
The units are controlled and monitored using the following analogue signals.
PARAMETER
MIN.
VALUE
MAX.
UNITS
Voltage control: 0 to 10V = 0 to Full scale output V
(i)
-1
+1
%
Voltage reference output (wrt signal ground)
10
V
Enable: Active low enable, input impedance.
Designed to be operated by TTL or CMOS logic or
open collector transistor.
10
kΩ
Voltage monitor: 0-10V for 0 to full scale output (wrt
signal ground)
-1
+1
%
Current monitor: 0-10V for 0 to full scale output (wrt
signal ground)
-1
+1
%
Note:
(i) a stable, low noise reference source is recommended to achieve full unit performance.
The following sections describe the various connections that can be used to control the
MPD HV units.
