The Sphere Astrolink is a fully automatic satellite dish system designed for fixed installation on vehicles, such as caravans and motorhomes, with a maximum speed of 130 km/h. It is engineered to automatically aim its antenna at geostationary television satellites, providing satellite TV reception. The system operates on a standard vehicle electrical system with a rated voltage of 12 Volts, though a separate DC to DC downconverter is required for 24V DC systems.

Function Description:

The Sphere Astrolink is an intelligent satellite TV reception antenna system that automatically aligns itself towards a preset satellite when located within the footprint of the selected satellite. The system's controller allows users to select a satellite using arrow buttons and confirm with an "OK" button. A "Lock LED" flashes during the search and becomes solid once the satellite is found. If the wrong satellite is selected, users can navigate to the correct one and confirm.

Before driving, the antenna must be returned to its HOME position by pressing the "HOME" button on the controller. The HOME position is when the antenna is completely folded down and facing backward. To fully turn off the unit, the "Power" button should be long-pressed when the unit is at HOME. Alternatively, for extended stays or to save power, the unit can be powered off by a short press of the "Power" button, allowing the signal to continue to the satellite TV receiver.

The system includes several LED indicators on the controller: "HOME LED," "Lock LED," and "GPS LED." When all cable connections are complete and the unit is powered on, all satellite LEDs will flash. The "HOME LED" and a selected satellite LED (defaulting to "VAST" or the last selected satellite) will become solid, indicating the antenna is ready. If the antenna is not at HOME, the "HOME LED" will flash while it moves to the HOME position. The "GPS LED" flashes while searching for the current location and becomes solid once confirmed. It is recommended to wait until both "HOME" and "GPS" LEDs are solid for faster and more precise satellite alignment. The Sphere Astrolink can still locate the satellite even without the GPS locked.

Important Technical Specifications:

Model: Sphere Astrolink 85cm
Dish Size (Offset dish): 86.0 (W) x 91.0 (L) cm
Dimension (L x W x H): 110.6 x 86.0 x 18.4 cm
Weight: 15.1 Kg
Work Condition: Stationary
Polarization: Linear (Horizontal / Vertical)
LNB Output: Dual Output
LNB Input Frequency: 11.7 ~ 12.75 GHz
LNB Output Frequency: 1000 - 2050 MHz
Angle Range: (EL) 0°~145° / (AZ) 390° / (SK) -60° ~ +60°
Satellite Searching Time: 80 seconds (Average)
Power Requirement: DC 12V
Power Consumption: 60W searching (4W standby)
Operating Temperature: -20°C ~ +60°C
Tuner: DVBS, DVBS2
GPS: 24 channels
Gear Drive: Heavy Duty Full Metal

Usage Features:

Automatic Satellite Alignment: The system automatically finds and locks onto preset satellites.
Controller Interface: A user-friendly controller with arrow buttons, "OK," "HOME," and "Mode" buttons for easy operation.
LED Indicators: Visual feedback on system status, including HOME, Lock, GPS, and satellite selection.
Home Position Function: Ensures the antenna is safely folded for travel.
Power Saving Mode: Allows the unit to be powered off while maintaining signal reception for extended stays.
Advanced Settings: Includes options to change the VAST STB Home Transponder (TP) for improved signal reception in low signal areas or bad weather. Specific instructions are provided for SatKing VAST Receivers and UEC DSD 4921 RV models.
Software Upgrade: The system supports software upgrades via a USB stick, ensuring the unit stays up-to-date.

Maintenance Features:

Factory Reset: A factory reset function is available to restore the unit to its default settings, which can be useful for troubleshooting.
Troubleshooting Guide: The manual provides a comprehensive troubleshooting section for common issues such as no function on power-on, failure to lock to a satellite, and mechanical problems. It advises checking cable connections, power input, battery polarities, LNB arm fitting, and trying different satellite parameters.
No Regular Maintenance Required: The product does not require regular maintenance, with all service to be carried out at approved service centers.
Warranty: The Sphere Astrolink comes with a 2-year warranty.
Installation Guidelines: Detailed instructions for assembly and installation, including mounting plate installation, fixing the antenna main unit, laying out junction boxes and cable holders, and battery connection. Emphasis is placed on using supplied cables and ensuring proper waterproofing during installation.
Safety Notes: Users are advised to read and follow operating instructions carefully, ensure correct installation with supplied cables, and inspect the antenna unit before driving to ensure it is properly folded. The manufacturer disclaims liability for damage due to unsuitable battery usage, incorrect installation, or wrong polarity.

Optional Accessories:

Sphere 2x4 Satellite TV Multiswitch: Increases LNB outputs to four, allowing simultaneous use of Foxtel IQ and VAST.
Sphere Mounting Kit: Available for transferring the Astrolink to another vehicle, including essential components like mounting plate, cables, and brackets.
Sphere 24V to 12V Down Converter: Required for operating the Astrolink on 24V vehicles.
