Not to be distributed without prior consent of SPI Lasers UK Ltd.
Slide: 17
FS-S00149-Rev A
Start Up/Shutdown Procedure for
Prism Laser.
29/06/2016
• NOTE: 24V Aux supply must be turned on before the diode power supply
• Enable line must not be high before turning on the 24V PSU. If enable is high, the laser will not enable and the line must be
cycled for the laser to work correctly.
• Setting Machine & Water controls
• Turn on Machine (Machine may control Chiller or House water)
• Turn on the Chiller or House water if external to machine (Ensure Flow to both Laser and beam delivery optics)
• Turn on 24V Auxiliary Supply to Laser Control
• Turn on Diode Power Supply
• Starting the Operation
• Set ENABLE High
• Laser Ready O/P High
• Set POWER SET High (0.5 to 10V = 5% to 100% Power)
• Set MODULATE High
• EMITTING O/P High (Laser emission status indicator now amber)
• Laser now delivering Output Power as requested.
• Shutting Down the Operation
• Set Modulate to Low
• Set Power Set to 0V
• Set Enable to Low
• Turn off Diode PSU (allow PSU to discharge)
• For a Full Shut Down State
• Turn Off 24V Auxiliary supply for control
• Laser is now in a shutdown state.
• For operation using Analogue Modulation mode consult SM-S00481 Prism Module Fiber Laser User Instructions
• Before following the process as shown, all machine interlocks, emergency stops and Beam Delivery Optics must be
in a safe position.
