Customer Requirements Pre Install
29/06/2016
Parameter
Min
Max
Units
Appearance
Clear and without sediment
-
Particle size
-
100
μm
Hardness (mg CaCO
3
per litre)
-
300
mg/l
Electrical conductivity at 25°C
22
2200
μScm
-1
pH
6.5
9.0
-
Cooling Water Requirements
Parameter
Min
Max
Units
Notes
Cooling Water
Temperature
18
30
ºC
It is important that condensation will not occur. Refer to
Section 15.1. of SM-S00481 redPOWER Prism OEM Fibre
Laser Instructions for Use
Input Pressure
-
6
bar
Flow Rate
10
l/min/kW
At 20°C water temperature.
Pressure Drop
Long Module
-
2.5
bar
Pressure Drop
Short Module
-
2.0
bar
Cooling Requirements (Base plate)
Rated Power
300W
500W
750W
1000W
1500W
Units
Chiller Capacity
900
1500
2250
3000
4500
W
Required Chiller Capacity
