Spirax Sarco 211 - Operation

IM-S03-08 ST Issue 3
7
T - 01
Air vent
Fig. 3 Typical installation - Oil storage tanks
Air vent
Bucket
trap
Bucket
trap
5. Operation
Under most conditions the trap will discharge condensate with a 'blast' type action. Under low
load and / or low pressure applications the discharge may tend to 'dribble'.
Condensate is discharged at steam temperature so due care must be given to the site of
the discharge.
