Spirax Sarco AEL7 Series User Manual

IM-P713-01 CTLS Issue 1
10
AEL7 Series Electric actuator
2.2 Series in the AEL7 range
Table 1 AEL7 Series Nomenclature
Actuator A -
Type E Electric
Action L Linear
Series 7 -
Thrust
1 1.2 kN 0.9 kN for AEL71T
2 2.0 kN
2.1 kN for AEL72T
3 4.0 kN
4 6.0 kN
5 8.0 kN
6 12.0 kN
7 15.0 kN
8 20.0 kN
Nominal
Stroke
1 20 mm
Stroke Setting from factory. For full stroke information and
adjustment, refer to IM-P713-01.
2 30 mm
3 50 mm
4 70 mm
Supply
Voltage
1 230 VAC
2 115 VAC
3 24 VAC
4 24 VDC
Speed
1 Low 0-0.7 mm/s (Refer to TI-P713-02)
2 Medium 0.8-1.5 mm/s
3 High 1.6+ mm/s
Control
Signal
F VMD 24 Vac
G VMD 110 Vac
J VMD 230 Vac
K VMD 24Vdc
P Modulating (0)4-20mA / 0(2)-10V Positioner
Failure Mode
X None
T Spring Non-retrofit option. Not suitable for 24Vdc
S Super-Capacitor Non-retrofit option. Not suitable for 24 Vac
Potentiometer
X None
A Potentiometer 1 x 1000Ω
