IM-P713-01 CTLS Issue 1
19
AEL7 Series Electric actuator
Table 6 AEL7 Actuator Power Consumption – 230 Vac
Actuator
Nomenclature
Thrust Spindle Speed Power
(W)
Nominal
Current
(A)
Starting
Current
(A)
AEL71111- - -
1 kN
0.2 mm/s 4.9 0.03 0.03
AEL71211--- 0.3 mm/s 5.8 0.03 0.03
AEL72211---
2 kN
0.3 mm/s 5.8 0.03 0.03
AEL72211--- 0.4 mm/s 11.0 0.05 0.05
AEL72231--- 1.7 mm/s 64.4 0.28 0.28
AEL73211---
4 kN
0.4 mm/s 11.0 0.05 0.05
AEL73221--- 0.8 mm/s 64.4 0.28 0.28
AEL74211--- 6 kN 0.6 mm/s 51.5 0.23 0.23
AEL75311---
8 kN
0.7 mm/s 130.0 0.70 1.50
AEL75321--- 1.2 mm/s 130.0 0.70 1.50
AEL76311--- 12 kN 0.4 mm/s 51.5 0.23 0.23
AEL77311--- 15 kN 0.4 mm/s 51.5 0.23 0.23
AEL78421--- 20 kN 0.8 mm/s 206.0 0.93 2.10
Table 7 AEL7 Actuator Power Consumption – 110 Vac
Actuator
Nomenclature
Thrust Spindle Speed Power
(W)
Nominal
Current
(A)
Starting
Current
(A)
AEL71112- --
1 kN
0.2 mm/s 4.9 0.05 0.05
AEL71212--- 0.3 mm/s 5.7 0.06 0.06
AEL72212---
2 kN
0.3 mm/s 5.7 0.06 0.06
AEL72212--- 0.4 mm/s 11.0 0.10 0.10
AEL72232--- 1.7 mm/s 14.5 0.07 0.07
AEL73212---
4 kN
0.4 mm/s 11.0 0.10 0.10
AEL73222--- 0.8 mm/s 14.5 0.07 0.07
AEL74212--- 6 kN 0.6 mm/s 51.5 0.47 0.47
AEL75312---
8 kN
0.7 mm/s 110.0 1.10 2.20
AEL75322--- 1.2 mm/s 110.0 1.10 2.20
AEL76312--- 12 kN 0.4 mm/s 51.5 0.47 0.47
AEL77312--- 15 kN 0.4 mm/s 51.5 0.47 0.47
AEL78422--- 20 kN 0.8 mm/s 200.0 2.00 4.50
