26
6.3.1 Commissioning - quick set-up
This section allows the user to carry out the minimum commissioning necessary to operate
the system for two typical applications.
It accepts the defaults set in the factory, so will only work if the original default settings have
not been altered. See default settings in Section 10, Technical information, to confirm.
Settings can then be tailored to suit the individual requirements of the customer / application
if required.
WARNING: It is essential that you comply with National / local regulations and
Guidance notes, and the boiler manufacturer’s recommendations. It is imperative
that the settings you have accepted will allow the boiler to operate in a safe manner.
Quick set-up
Commissioning examples of two typical steam boiler applications:
Parameter Action
Lhi
Set water level to top of gauge glass (100%) and press the
OK
button.
Llo
Set water level to bottom of gauge glass (0%) and press the
OK
button.
WARNING – WATER LEVEL MUST STILL BE VISIBLE IN THE GAUGE GLASS
Note: For correct operation level the input and feedback potentiometer should be calibrated.
- ON / OFF control (pumping in), using an LP20 / PA20.
High and Low level alarm
CtL
Select on / oFF and press the
OK
button.
- Modulating control (pumping in) using an LP20 / PA20 and a VMD
actuator.
High and Low level alarm
CtL
Select PrO and press the
OK
button.
Phl
Potentiometer High – Calibrates the valve to the open position.
The valve will open automatically. Press
OK
when fully open.
PLo
Potentiometer Low – Calibrates the valve to the closed position.
The valve will close automatically. Press
OK
when fully closed.
Test the system is working correctly
