Page #37 background imageLoading...
Page #37 background image
IM-P402-130 EMM Issue 9
37
10.5 Cable / wire and connector data
Mains and signal connector
Termination
Rising clamp plug-interminal blocks with screwed
connectors
Cable size 0.2 mm² (24 AWG) to 2.5 mm² (14 AWG)
Stripping length 5 - 6 mm
Caution: use only the connectors supplied by Spirax Sarco Ltd. Safety and Approvals may
be compromised otherwise.
Level probe and feedback cable / wires
Type High temperature
Shield type Screened
Number of cores 3
Gauge 1 - 1.5 mm² (18 - 16 AWG)
Maximum length 100 m (328 ft)
Recomended type Pirelli (Prysmian) FP200, Delta Crompton Firetuf OHLS
4 - 20 mA output cable / wires
Type Twisted pair
Shield type Screened
Number of pairs 1
Gauge 0.23 - 1 mm² (24 - 18 AWG)
Maximum length 100 m (328 ft)
Recommended type Various
