Spirax Sarco SP200 - Mounting to Linear Actuator

IM-P343-29 CH Issue 512
5.2.1 Loosely attach the magnet bracket (2) to the valve / actuator connector (refer to
Figures 4 and 5). Be sure it is positioned horizontally (as shown in Figure 5).
Fig. 4 Pillar mounting kit for a linear actuator
Fig. 5
Yoke mounting
assembly for a
linear actuator
5.2 Sequence for mounting an SP200 positioner to a
linear actuator
2
2
