IM-P343-29 CH Issue 536
Display = 100%
Display = 0%
Display = 100%
Display = 0%
Fig. 35 2-port valve normally open - TRAVL setting = 100% to 0%
Fig. 36 2-port valve normally closed - TRAVL setting = 100% to 0%
