IM-P343-29 CH Issue 544
9.5.7 MIN-R - minimum signal span range
Programming notes
Enables the minimum mA input signal span range to be set. The value set will
correspond to the minimum travel setting. Default value is 4 mA.
Use and keys to alter the displayed value. Minimum difference between
MIN-R and MAX-R is 4 mA.
Press
key to accept the displayed value and advance to the maximum mA
input span range (MAX-R).
Commissioning notes
This function can be used to set split range applications i.e. 4 - 12 mA or 12 - 20 mA.
To ensure tight shut-off refer to Section 9.6.2 S-MIN, page 46.
9.5.8 MAX-R - maximum signal span range
Programming notes
Enables the maximum mA input signal span range to be set. The value set will
correspond to the maximum travel setting. Default value is 20 mA.
Use and keys to alter the displayed value. Minimum difference between
MIN-R and MAX-R is 4 mA.
Press key to accept the displayed value and return to SET in the main
menu.
Commissioning notes
This function can be used to easily set split range applications i.e. 4 - 12 mA or 12 - 20 mA.
To ensure tight shut-off refer to Section 9.6.3 S-MAX, page 47.
