IM-P343-29 CH Issue 58
3.2 Technical data
Input signal range 4 - 20 mA nominal
Minimum input signal (loop powered) 3.6 mA
Minimum air supply pressure 1.0 bar g above maximum spring range pressure
(Note: For the PN5120 actuator, the supply air pressure should be set at 1.5 bar g)
Maximum air supply pressure 6.0 bar g
Air quality
Air supply must be dry, oil and dust free to
ISO 8573-1 class 2:3:1
Output pressure 0 to 100% supply pressure
Stroke range
Linear valves 10 mm to 100 mm
Quarter turn valves 5° to 120°
Action
Single action / fail vent
Double action / fail vent output 1, fill output 2
Operating temperature -10°C to +80°C
Maximum air flow
4.2 normal m
3
/h at 1.4 bar g or
8.5 normal m
3
/h at 6 bar g
Steady state air consumption Less than 0.035 normal m
3
/h
Air connections Screwed ¼" NPT
Cable gland Pg 13.5
Electrical connections Spring clamp terminals for 0.2 to 1.5 mm² wire
Enclosure rating IP65
Characteristic
Linear, Equal % (ratio 1:50) or
Fast opening (ratio 50:1)
Resolution (maximum) 0.1% F.S.
Shipping weight 3.2 kg
3.3 Materials
Part Material Finish
Case and cover Die cast aluminium Anti-corrosive paint to RAL5010
Magnet bracket Die cast aluminium
3.4 Model SP200is – ATEX certification
EC-type Certificate N. . IMQ 07 ATEX 011
Classification
II 2GD
Ex ia
IIC T6 / Ex iaD 21 T85°C (Tamb -20 to +40°C)
Ex ia IIC T5 / Ex iaD 21 T100°C (Tamb -20 to +65°C)
Ex ia
IIC T4 / Ex iaD 21 T135°C (Tamb -20 to +80°C)
