Spirent C1 and C2 Installation Instructions
System Description
16 | Spirent C1 and C2 Installation Instructions
PN 71-008959 Rev A April 2020
SPT-C2 8 x 10G/5G/2.5G/1G/100M (Dual NIC-63)
The connector panel is shown in Figure 10.
Figure 10. SPT-C2 8 x 10G/5G/2.5G/1G/100M (Dual NIC-63)
The network data cables (customer supplied) connected to these ports must be as follows:
• Ethernet CAT-5 cable for the management port (Eth0)
• For test ports (1-8)
• Copper: RJ45 connector, Ethernet CAT-5e or better cable
Note: Refer to the Spirent C1 and C2 Quick Reference for additional details about the
SPT-C2 cables and connectors.
