Spirent C1 and C2 Installation Instructions
Multiple Chassis and External Time Reference (ETR) Connectors on SPT-C2
26 | Spirent C1 and C2 Installation Instructions
PN 71-008959 Rev A April 2020
Note: If you are connected using SSH, you will lose connectivity when you use the
activate command. You must power cycle the appliance manually, or log back in to the
appliance using the new IP address. You must then use the reboot command below, before
the product's GUI or script can access the appliance.
admin(hypervisor)>>reboot – Applies your settings and reboots
the appliance.
When the SPT-C1/SPT-C2 appliance restores, after the power cycle or reboot, it is ready
for use with the product’s GUI or an automation script (if supported in your current
release).
For a complete list of the admin commands available for the SPT-C1/SPT-C2 appliance,
refer to Table 7 on page 33.
Multiple Chassis and External Time Reference (ETR)
Connectors on SPT-C2
Multiple Chassis Connectors
SYNC IN and SYNC OUT Connectors
These RJ-45 connectors are used to interconnect multiple Spirent chassis/appliances. The
SYNC OUT on the Sync Master is connected to the SYNC IN on the Sync Slave. For
longer multiple chassis chains, the SYNC OUT on the Sync Slave is connected to the
SYNC IN of the next Sync Slave. This connection arrangement can theoretically
accommodate up to 255 chassis.
External Time Reference (ETR) Connectors
The Spirent chassis contains these connectors that are currently supported for use with
External Time Reference (ETR) equipment connections: the External Time Reference
Serial DCE connector RJ-45); the External Time Reference 10 MHz connector (SMA);
and the External Time Reference 1 PPS connector (SMA).
Note: Refer to FAQ18073 for information about External Time Reference (ETR)
methods you can use to sync multiple remote chassis. Type FAQ18073 in the CSC Search
box. Press Enter.
