1PREFACE
1.1 About the device
This Spirotech product improves the quality of your
complete installation.
• For an overview of the product, refer to section 2.1.
• For the intended use, refer to section 2.3.
This Spirotech product is designed and manufactured
according to the Sound Engineering Practice as stated in
the Pressure Equipment Directive (2014/68/EU).
This manual applies to product types starting with the
codes shown below:
/i
/i
1.2 About this document
Read the instructions before installation, commissioning
and operation. Keep the instructions for future reference.
The original language of the document is English. All
other available language versions are translations of the
original instructions.
The illustrations in this document show a typical setup
with relevant details for instructional use only.
Differences between the illustrations and the device are
possible but do not have an effect on the
comprehensibility of this document.
All rights reserved. No part of this manual may be
duplicated and/or made public through the Internet, by
means of printing, photocopying, microfilm or in any
other way without prior written permission from
Spirotech bv.
This manual has been composed with the utmost care.
Should, however, this manual contain any inaccuracies,
Spirotech bv cannot be held responsible for this.
1Preface 2
2 Introduction 4
3 Technical specifications 6
4Safety 8
5 Installation and commissioning 8
6 Preventive maintenance 11
7 Failures 13
8 Guarantee 14
BA...XC 050...300 F - G - L M
Code Description
BA
SpiroVent
HA
BC
SpiroCombi
HC
BD
HD
BE
SpiroTrap
HE
BF
HF
XC SpiroCross
... Connections size (DN) code:
• 050: DN50
• 065: DN65
• 080: DN80
• 100: DN100
• 125: DN125
• 150: DN150
• 200: DN200
• 250: DN250
• 300: DN300
FFlanged
L Welded ends
G Victaulic (grooved)
MMagnet
NOTE
Products with a product code ending with "S"
(Special manual, e.g. BAS
050F) are excluded
in this manual, if not otherwise mentioned.
