Spitronics Simulator3 Manual
Spitronics Simulator3 Manual Ver 1.0 Page 10 of 11
Program 19 …………………………18-6 TDC Home Gear - 18 Pulse/Rpm
(1. 12 Teeth Crank Pulse with 3x2 Tooth Slot)
(2. 1 Tooth Cam Home Pulse - 180°)
11.2. Distributors
Program Trigger
Program 30 ………………………...TEST Program
(1. Crank Pulse)
(2. TDC Pulse)
(3. Cam1 Pulse)
(4. Cam2 Pulse)
Program 31………………………….24+TDC - 12 Pulse/Rpm
(1. 24 Teeth Distributor Pulse)
(2. TDC Distributor Pulse)
Program 32 ………………………...Nissan 4Cyl - 30 Pulse/Rpm - Hall Sensors
(1. 4 x Progressive Slots Smaller)
Program 33………………………....Nissan 6Cyl - 45 Pulse/Rpm - Hall Sensors
(1. 6 x Progressive Slots Smaller)
Program 34 ………………………...Nissan V8 - 45 Pulse/Rpm - Hall Sensors
(1. 4 x Progressive Slots Smaller + 4 x Intermediate Pulses)
Program 35 ………………………...Ford Slots 8Cyl - 60 Pulse/Rpm - Hall Sensors
(1. 8 Slots 1 Large 7 Small (Positive Edge))
(Channel 2 Inverted (Negative Edge))
Program 36 ………………………...Daewoo Matiz 60-6 30 Pulse/Rpm - Magnetic
