1. Introduction
The Spitronics Simulator is a diagnostic tool designed to help you test Spitronics products.
The Spitronics simulator is compatible with:
- Spitronics ECU’s; EMU, TITAN, VENUS, PLUTO, PLUTO2, SATURN MERCURY and MERCURY2
- TCU’s; TITAN, NEPTUNE, NEPTUNE2, MERCURY and MERCURY2
- Firing modules; F10, F11 and all newer modules
- Idle control1/2; TYPE 1 and 2
- Selective non Spitronics management units with the correct harness for the simulator.
Please read through the manual to make sure you follow the correct setup requirements.
2. Hardware Setup
Important!
ECU’s is automatically grounded through the 12 way connector, do not apply a separate
ground to the unit, unless testing an old EMU or a TITAN TCU
Power is supplied to the simulator through the 12V jack that is fitted to the simulator either
through the 12V power supply sold with the unit or battery.
2.1. Connecting Instructions
1. Connect the power supply to the 12V jack on the simulator.
2. Connect the unit (MERCURY, VENUS etc.).
3. Make sure the green power (PWR) LED on the simulator comes on when power is
applied. Also the units LED’s will switch on and this will signify that the unit is
powered up.
