Spitronics Simulator3 Manual Ver 1.0 Page 8 of 11
10. Simulator Harness
Note
The simulator has a series of different harnesses for different applications, make sure
you have the correct harness.
11. Trigger Table
11.1. Crank Gears
Program Trigger
Program 01 ……………….………..8-1 Gear - 16 Pulse/Rpm
(1. 8 Teeth Crank Pulse with 1 Tooth Slot)
Program 02 ……………….……….12-1 Gear - 12 Pulse/Rpm
(1. 11 Teeth Crank Pulse with 1 Tooth Slot)
Program 03 …………….………….12+1 Gear - 60 Pulse/Rpm - Magnetic
(1. 12 Teeth Crank Pulse with 1 TDC Tooth
Program 04 ……………….……….12+Home Gear - 12 Pulse/Rpm
(1. 12 Tooth Crank Pulse)
(2. 1 Tooth Cam Home Pulse)
Program 05 ……………….……….18-1 Gear - 18 Pulse/Rpm
(1. 17 Teeth Crank Pulse with 1 Tooth Slot)
Program 06 ………………….…….24-1 - 24 Pulse/Rpm - Magnetic
(1. 23 Teeth Crank Pulse with 1 Tooth Slot)
Program 07 ……………….……….24-2 Gear - 24 Pulse/Rpm
