Spitronics Simulator3 Manual Ver 1.0 Page 3 of 11
3. Inputs and Outputs
3.1. LED Indicators : ECU
The LED's will indicate all simulated outputs:
Relay = Fuel Relay E-Relay = Electronic Relay
P7 = Positive Coil Driver 7 P8 = Positive Coil Driver 8
P5 = Positive Coil Driver 5 P6 = Positive Coil Driver 6
P3 = Positive Coil Driver 3 P4 = Positive Coil Driver 4
P1 = Positive Coil Driver 1 P2 = Positive Coil Driver 2
GP1 = General Purpose Output 1 RPM = RPM Output
N1 = Negative Injector Driver 1 N2 = Negative Injector Driver 2
N3 = Negative Injector Driver 3 N4 = Negative Injector Driver 4
N5 = Negative Injector Driver 5 N6 = Negative Injector Driver 6
N7 = Negative Injector Driver 7 N8 = Negative Injector Driver 8
GP2 = General Purpose Output 2 5V = Monitor the Units 5V Output
PWR = Power TRIG = Simulator Trigger
3.2. Turning Knobs : ECU
The Turning knobs simulates all inputs:
TPS = Throttle Position Sensor RPM = Engine Revolutions per minute
POT = Potentiometer Cam1 = Cam Sensor Degrees
MAP = Manifold Absolute Pressure Sensor Cam2 = Cam Sensor Degrees
Altitude = Altitude Pressure Sensor Speed = Road Speed
Water = Water Temp Sensor Lambda = Exhaust Gas Sensor
Air = Air Temp Sensor Fuel Pressure = Fuel Pressure Sensor
