SPL Director - Remote Control Learning

14
Operation
IR Remote Control
Volume
Volume of the Director can be remotely controlled using any infrared (IR) remote control.
The special feature is that the Director learns your remote and not the other way around. You do not need a uni-
versal remote control. Take, for example, the remote control of the CD player. Out of the many buttons there are
two you hardly use if at all and that do not directly trigger a function on the CD player. Assign Volume up / Volume
down to these two buttons and let the Director learn them.
• Press the PGM IR VOLUME button () on the rear of the unit until you note the actuation point.
Power LED now lights up brighter.
• Point your remote control towards the IR receiver () and push the button you wish to use to
lower the volume. The power LED flashes once per push. Press the same button repeatedly until
the power LED flashes three times within a short interval – programming this button is then com-
pleted.
• Point your remote control towards the IR receiver () and push the button you wish to use to increase the
volume. The power LED flashes once per push. Press the same button repeatedly until the power LED
flashes three times within a short interval – programming this button is then completed.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
ATTENTION
USB
AES
OPTICAL
COAX
L
R
L
R
L
12
ANALOG < SOURCES > DIGITAL
1 ON: RCA Direct Out
2 ON: XLR Direct Out
5 ON: Ref +15dB
6 ON: Ref +18dB
3 ON: Zero flag auto-mute enabled
4 ON: RCA In -10dBV to 0dBuON BOTTOM SIDE:
DIP SWITCHES
Made in
Germany
OUT OUT R OUT L
R
B
A
Voltage Selection: 1. Remove Fuse Holder
2. Exchange Fuses 3. Flip Over 4. Reinstall
~115 V AC/~230 V AC, 50 Hz/60 Hz, P max. 45 W
Fuses: 230 V: T 500mA L 250V, 115 V: T 1 A L 250V
AMP CTL
IR
PGM
IR
PGM
SOURCE
VOLUME
Refer to
Manual
