AMP CTL (Amplier Control)
AMP CTL (Amplier Control)
If you connect the Director via AMP CTL () to the SPL Performer s power amp, the Director
switches both units between standby and operation together. Use a . mm mono mini jack cable.
The Director offers two outputs (A and B) in case you use two Performer s in bridge mode or
in a bi-wiring application.
